- Description
- Specification
• 5MP high-performance CMOS
• 2560 × 1944 resolution
• 3.6mm fixed focal lens
• EXIR 2.0, smart IR, up to 40 m IR distance
• OSD menu, 2D DNR, DWDR
• 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
• IP67
• Up the Coax
Image Sensor | 5MP CMOS image sensor |
---|---|
Resolution | 2592 (H) × 1944 (V) |
Min. illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
Lens | 3.6mm |
Horizontal Field of View | 80.1° |
Lens Mount | M12 |
Day & Night | IR cut Filter |
Angle Adjustment | Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360° |
Synchronization | Internal synchronization |
Frame Rate | PAL: 5 MP@20fps, 4MP@25fps, 1080p@25fps / NTSC: 5MP@20fps, 4MP@30fps, 1080p@30fps |
AGC | Support |
D/N Mode | Auto/Color/BW (Black and White) |
White Balance | ATW/MWB |
BLC | Support |
Digital Wide Dynamic Range | Support |
Language | English |
Functions | Brightness, Sharpness, Digital noise reduction, Mirror, Bad pixel correction, Smart IR |
Video Output | 1 HD analog output |
Switch Button | TVI/AHD/CVI/CVBS |
Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
Power Supply | 12 VDC ±25% |
Power Consumption | Max. 4.3 W |
Protection Level | IP67 |
Material | Enclosure: Plastic / Main body: Metal |
IR Range | Up to 40 m |
Communication | Up the coax |
Dimensions | Ø 110 mm × 93.2 mm (Ø 4.33″ × 3.67″) |
Weight | 350 g (0.77 lb.) |
