• 24/7 Full Time Color Turret
• H.265+ Video Compression
• 4MP (2688×1520) Resolution
• 4mm Fixed Lens
• 100 FT Visible Light Range
• 120dB WDR, 3 Axis
• Built-in Micro SD Card Slot
• DC12V, PoE
| MODEL | GS-TC344-XD/LU |
| Camera | |
| Image Sensor | 1/1.8″ Progressive Scan CMOS |
| Min. Illumination | 0.0014 Lux @ (F1.0, AGC On), 0.0 Lux with Light |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Lens | 4mm @ F1.0, Angle of View: 94° |
| Lens Mount | M16 |
| Angle Adjustment | Pan: 0° – 360°, Tilt: 0° – 75°, Rotation: 0° – 360° |
| Digtal Noise Reduction | 3D DNR |
| Wide Dynamic Range | 120dB |
| Compression Standard | |
| Video Compresson | H.265+ / H.264+ / MJPEG |
| H.265 Type | Main Profile |
| Video Bit Rate | 32 Kbps – 16 Mbps |
| Dual Steam | Support |
| Image | |
| Max. Resolution | 2688 x 1520 |
| Frame Rate | 50 Hz: 25 FPS (2688×1520), 25 FPS (2304×1296), 25 FPS (1920×1080)
60 Hz: 30 FPS (2688×1520), 30 FPS (2304×1296), 30 FPS (1920×1080) |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness |
| BLC | Support, Zone Configurable |
| ROI Codec | Support |
| Network | |
| Network Storage | NAS (Support NFS, SMB/CIFS), ANR |
| Alarm Trigger | Intrusion Detection, Line Crossing Detection, Motion Detection, Tampering Alarm |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP |
| Standard | ONVIF, PSIA, CGI, ISAPI |
| General | One-key reset, Dual stream, Privacy mask, User Authentication, Watermark |
| General | |
| Operating Conditions | -30°C ~ 60°C (-22°F ~ 140°F) |
| Power Supply | 12VDC, PoE (802.3af) |
| Power Consumption | Max. 7.5W |
| Ingress Protection | IP67 |
| Visible Light Range | Approx. 100 FT |
| Dimension | 5.4″ x 4.9″ |
| Weight | 2 LBS |
