8MP 4K PTZ PoE IP Dome Camera Outdoor with 2 Way Audio
- Pan Tilt 5X Optical Zoom
- Human and Vehicle Detection
- Color Night Vision
- 150ft Night Vision
- IK10 &I P67
- H.265+
- SD Card slot
- 4PCS Array IR * Warm LED
| Model | IPPTZ987T-5X |
| Camera | |
| Image Sensor | 1/2.8″ Sony CMOS |
| Effective Pixels | 8 megapixels |
| Electronic Shutter | AUTO, 1/10s ~ 1/100000s |
| Min. Illumination | 0.01Lux@F1.2(AGC ON) |
| Day/Night | Auto/Color/(B/W)/Timing |
| WDR | Digital WDR |
| White Balance | Auto/Manual |
| BLC /HLC | Support |
| DNR | 2D/3D DNR |
| Other | Image adjust , Flip |
| Encode | |
| Video Standard | H.265+/H.265/H.264/MJPEG |
| Video Resolution | MainStream:25/30fps@8MP(3840×2160),25/30fps@6MP(3072×2048)/5MP(2592×1944)/4MP/3MP/1080P/720P,etc. |
| Sub stream: 720×480/VGA(640×480)/360P/QVGA@25/30fps,etc. | |
| Third stream:1080P/720P/CIF@10fps | |
| Video Bitrates | 512Kbps – 12Mbps, VBR/CBR |
| Audio Standard | G.711-u/G.711-a/AAC |
| Two-way Audio | Yes |
| Smart Detection | Smart Human body and Vehicle Detection |
| Micro-SD Slot | Max. 512G |
| Reset Key | Yes |
| IR&warm light Led | |
| Led | 2pcs IR Array LEDs+2pcs soft and warm lighting Leds |
| Distance | 40 m (IR), 30 m (warm light) |
| Lens | |
| Focal length | 2.7-13.5 mm motorized zoom and AF lens |
| Zoom | 5x optical zoom |
| PTZ | |
| Pan/Tilt Range | Pan: 0° ~ 280°; Tilt: 0° ~ 90° |
| Preset Point | 10 |
| Control Speed | Pan: 15° /s; Tilt: 15° /s |
| Guard Position | Support |
| Power-off Recovery | Support |
| Network Services | |
| Protocol | HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP, etc. |
| P2P | Yes |
| Web | IE, Firefox, Chrome, Edge, Safari |
| Media | CMS, Android, IOS |
| ONVIF | 17.06 compatible |
| General | |
| Network Port | 1-RJ45, 100Mbps, PoE 48V in |
| Power Supply | 12 VDC ± 10% 2A |
| Power Consumption | < 15 W |
| Operating Temp. | -30℃-(+60)℃, 10%-90%RH |
| Size | Φ120(mm)×110(mm) |
| Weight | 0.68kg |
