GS-ACC-HDMIEXTENDER-WIFI-100M
HDMI EXTENDER WIRELESS 1080P 100M WITH HDMI LOOP-OUT, IR
- Description
- Specification
- Support the highest Resolution up to 1080P@60Hz YUV 4:4:4 8bit (both of input and output)
- Support the longest distance to 100M wireless transmitted under certain conditions, like open space/horizontal height of equipment, etc
- Support HDCP 1.4, compatible with HDCP 2.2 Blu-Ray player, decryption output
- Support 100-230V voltage input, DC12V power supply
- With prompt to video output interface
- Support IR control with long distance
- Built in reset button
| Operating Temperature Range | 0 to +40℃(+32 to +104℉) |
| Operating Humidity Range | 10 to90%RH (No Condensation) |
| Connectors on Transmitter | HDMI Receptacle x 2 (1xHDMI input, 1xHDMI loop output)
Power DC Receptacle x 1 IR Receptacle x 1(for IR TX ) |
| Connectors on Receiver | HDMI Receptacle x 1
IR Receptacle x 1(for RX cable) |
| Resolution outputs | 1080p/1080i/720p/576p/480p |
| Audio format supported | Uncompressed audio PCM 2.0 |
| Output Video Signal | HDMI |
| Dimension (L×W×H) | TX: L170xW114.8xH26mm; RX: L170xW114.8xH26mm |
| Power supply | DC 12V 1A Power supply |
| Power consumption | 4W(MAX) |
| Transmission Distance | 1080p up to 100m |
| Net Weight | TX: 200g; RX:180g |
